| Complete Vehicle | |
| Model | YX-22F |
| Sweeping Width | 2200 mm |
| Main Brush Width | 700 mm |
| Working Efficiency | 8000 – 13500 m²/h |
| Working Hours | 3 – 8 h |
| Dustbin Capacity | 180 L |
| Side-Brush Diameter | 600 mm (x4) |
| Walking Speed | 0 – 14 km/h |
| Overall Dimensions (L x W x H) | 2260 x 2200 x 2000 mm |
| Water Tank | 80 L |
| Vacuum Filtration Area | 6 m² |
| Tire Type | Front 400-8 / Rear 400-8 Solid Tire |
| Control Mode | Intelligent Control System (with Timed Dust Shaking) |
| Warning Lights | |
| Headlight | Four-Way LED Headlights |
| Tail Light | Steering + Braking + Driving Integrated Taillights |
| Alarm Lamp | Top Operation Warning Light |
| HD Reverse Camera | Yes |
| Storage Battery | |
| Battery Type | Lead-Acid Maintenance-Free (Lithium Battery Optional) |
| Battery Capacity | 48V — 100AH x4 / 150AH x6 (Standard) |
| Electrical Machinery | |
| Walking Motor | 1000 W (Intelligent Gear Change) |
| Rolling Brush Motor | 1000 W |
| Side-Brush Motor | 4 x 100 W |
| Motor Voltage | 48 V |
| Rearview Mirror | |
| Model | Dedicated for Sweeping Vehicles |
